springBoot2集成activiti，集成activiti在线设计器

时间：2019-02-21 11:39:00 收藏：0 阅读：550

摘要

本篇随笔主要记录springBoot2集成activiti流程引擎，并且嵌入activiti的在线设计器，可以通过浏览器直接编辑出我们需要的流程，不需要通过eclipse或者IDEA的actiBpm插件设计流程再直接部署到项目下，页面保存流程后可直接发布、发起流程。
所需软件版本
springBoot 2.0.1.RELEASE
activiti 5.22.0 官网下载地址
activiti-webapp-explorer2 我的github上的explorer项目

集成方法
activiti支持多种数据库，本身还有个h2的内存数据库，我这里用的是Mysql
1、pom.xml引入依赖，这里主要是activiti的依赖包，${activiti.version}为5.22.0

 <!--spring activiti start-->
        <dependency>
            <groupId>org.activiti</groupId>
            <artifactId>activiti-spring-boot-starter-basic</artifactId>
            <version>${activiti.version}</version>
            <exclusions>
                <exclusion>
                    <groupId>org.springframework.boot</groupId>
                    <artifactId>spring-boot-starter-actuator</artifactId>
                </exclusion>
                <exclusion>
                    <groupId>org.springframework.boot</groupId>
                    <artifactId>spring-boot-starter-web</artifactId>
                </exclusion>
                <exclusion>
                    <groupId>org.springframework.security</groupId>
                    <artifactId>spring-security-config</artifactId>
                </exclusion>
            </exclusions>
        </dependency>
        <dependency>
            <groupId>org.activiti</groupId>
            <artifactId>activiti-spring-boot-starter-actuator</artifactId>
            <version>${activiti.version}</version>
            <exclusions>
                <exclusion>
                    <groupId>org.springframework.boot</groupId>
                    <artifactId>spring-boot-starter-web</artifactId>
                </exclusion>
            </exclusions>
        </dependency>
        <dependency>
            <groupId>org.activiti</groupId>
            <artifactId>activiti-rest</artifactId>
            <version>${activiti.version}</version>
            <exclusions>
                <exclusion>
                    <groupId>org.springframework.security</groupId>
                    <artifactId>spring-security-config</artifactId>
                </exclusion>
            </exclusions>
        </dependency>
        <dependency>
            <groupId>org.activiti</groupId>
            <artifactId>activiti-explorer</artifactId>
            <version>${activiti.version}</version>
            <exclusions>
                <exclusion>
                    <groupId>com.vaadin</groupId>
                    <artifactId>vaadin</artifactId>
                </exclusion>
                <exclusion>
                    <groupId>org.vaadin.addons</groupId>
                    <artifactId>dcharts-widget</artifactId>
                </exclusion>
                <exclusion>
                    <groupId>activiti-simple-workflow</groupId>
                    <artifactId>org.activiti</artifactId>
                </exclusion>
            </exclusions>
        </dependency>
        <dependency>
            <groupId>org.activiti</groupId>
            <artifactId>activiti-diagram-rest</artifactId>
            <version>${activiti.version}</version>
        </dependency>
        <dependency>
            <groupId>org.activiti</groupId>
            <artifactId>activiti-simple-workflow</artifactId>
            <version>${activiti.version}</version>
        </dependency>
        <dependency>
            <groupId>org.activiti</groupId>
            <artifactId>activiti-spring</artifactId>
            <version>${activiti.version}</version>
        </dependency>
        <dependency>
            <groupId>org.apache.xmlgraphics</groupId>
            <artifactId>batik-codec</artifactId>
            <version>1.7</version>
        </dependency>
        <dependency>
            <groupId>org.apache.xmlgraphics</groupId>
            <artifactId>batik-css</artifactId>
            <version>1.7</version>
        </dependency>
        <dependency>
            <groupId>org.apache.xmlgraphics</groupId>
            <artifactId>batik-svg-dom</artifactId>
            <version>1.7</version>
        </dependency>
        <dependency>
            <groupId>org.apache.xmlgraphics</groupId>
            <artifactId>batik-svggen</artifactId>
            <version>1.7</version>
        </dependency>
        <dependency>
            <groupId>org.springframework.security</groupId>
            <artifactId>spring-security-config</artifactId>
            <version>4.1.3.RELEASE</version>
        </dependency>

        <!--spring activiti end-->

2、拷贝项目资源
　　解压activiti-webapp-explorer2，把webapp下面的diagram-viewer、editor-app、modeler.html复制到springboot项目下的static下，这是activiti的在线设计器，modeler.html就是设计的主界面，复制resources下stencilset.json到自己的resources下。
　　

　　解压activiti-5.22.0的包，将libs下的activiti-modeler-5.22.0-sources.jar解压出来，把org\activiti\rest\editor路径下的main、model文件夹复制到springboot项目的源码路径下，里面有三个类，主要用于读取stencilset.json。

3、修改拷贝过来的资源文件
　　修改StencilsetRestResource.java、ModelEditorJsonRestResource.java、ModelSaveRestResource.java3个controller，加上@RequestMapping("/service")

　　修改editor-app下的app-cfg.js，把contextRoot后面改成 /service，和controller里面加的requestMapping要一致

var ACTIVITI = ACTIVITI || {};

ACTIVITI.CONFIG = {
    ‘contextRoot‘ : ‘/service‘,
};

4、新增service、controller
　　service实现，这里只放实现类，接口就不放了，自己可以根据实现类自己添加接口方法，这个service实现了把流程和自定义表单结合的功能，completeTask方法通过java反射执行不同任务节点执行不同form

package com.djkj.activiti.service.Impl;

import com.djkj.activiti.bean.ActivitiVariable;
import com.djkj.activiti.common.BusinessTaskUtil;
import com.djkj.activiti.service.ActivitiService;
import com.djkj.activiti.service.ActivitiVariableService;
import org.activiti.bpmn.model.BpmnModel;
import org.activiti.engine.HistoryService;
import org.activiti.engine.RepositoryService;
import org.activiti.engine.RuntimeService;
import org.activiti.engine.TaskService;
import org.activiti.engine.delegate.DelegateExecution;
import org.activiti.engine.history.HistoricActivityInstance;
import org.activiti.engine.history.HistoricProcessInstance;
import org.activiti.engine.impl.cfg.ProcessEngineConfigurationImpl;
import org.activiti.engine.impl.persistence.entity.ProcessDefinitionEntity;
import org.activiti.engine.impl.pvm.PvmTransition;
import org.activiti.engine.impl.pvm.process.ActivityImpl;
import org.activiti.engine.runtime.ProcessInstance;
import org.activiti.engine.task.Task;
import org.activiti.image.ProcessDiagramGenerator;
import org.apache.log4j.Logger;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;
import sun.misc.BASE64Encoder;

import javax.imageio.ImageIO;
import java.awt.image.BufferedImage;
import java.io.ByteArrayOutputStream;
import java.io.File;
import java.io.FileOutputStream;
import java.io.InputStream;
import java.lang.reflect.Method;
import java.util.*;

@Service
public class ActivitiServiceImpl implements ActivitiService {

    @Autowired
    private RuntimeService runtimeService;
    @Autowired
    private TaskService taskService;
    @Autowired
    private HistoryService historyService;
    @Autowired
    private RepositoryService repositoryService;
    @Autowired
    private ProcessEngineConfigurationImpl processEngineConfiguration;
    @Autowired
    private ActivitiVariableService activitiVariableService;

    private static final Logger logger=Logger.getLogger(ActivitiServiceImpl.class);

    /**
     * 启动流程
     */
    @Override
    public void startProcesses(String id,String business_key) {
        ProcessInstance pi = runtimeService.startProcessInstanceByKey(id, business_key);//流程图id，业务表id
        System.out.println("流程启动成功，流程id:"+pi.getId());
    }

    /**
     *
     * <p>描述: 根据用户id查询待办任务列表</p>
     * @author 范相如
     * @date 2018年2月25日
     */
    @Override
    public List<Task> findTasksByUserId(String userId) {
        List<Task> resultTask = taskService.createTaskQuery().processDefinitionKey("process").taskCandidateOrAssigned(userId).list();
        return resultTask;
    }

    @Override
    public Task findTaskById(String taskId){
        List<Task> resultTask = taskService.createTaskQuery().taskId(taskId).list();
        if(resultTask!=null){
            return resultTask.get(0);
        }
        return null;
    }

    /**
     *
     * <p>描述:任务审批     （通过/拒接） </p>
     * @author 范相如
     * @date 2018年2月25日
     * @param taskId 任务id
     * @param userId 用户id
     * @param result false OR true
     */
    @Override
    public void completeTask(String taskId,String userId,String result) {
        //获取流程实例
        taskService.claim(taskId, userId);
        //获取任务
        Task task=taskService.createTaskQuery().taskId(taskId).singleResult();
        //获取流程实例ID
        String proInsId = task.getProcessInstanceId();
        //获取流程实例
        ProcessInstance process = runtimeService.createProcessInstanceQuery().processInstanceId(proInsId).singleResult();
        //获取业务外键
        String business_key = process.getBusinessKey();
        String[] array = business_key.split(":");
        String business_Id = array[1];
        //业务处理
        try {
            Class clazz=BusinessTaskUtil.class;
            Object obj = clazz.newInstance();
            Method method = clazz.getMethod("actBusiness_"+task.getFormKey(),String.class,String.class,String.class);
            method.invoke(obj,userId,business_Id,result);
        }catch (Exception e){
            e.printStackTrace();
            logger.error("执行业务方法错误！");

        }
        taskService.complete(taskId);
    }

    /**
     * 更改业务流程状态#{ActivityDemoServiceImpl.updateBizStatus(execution,"tj")}
     * @param execution
     * @param status
     */
    @Override
    public void updateBizStatus(DelegateExecution execution, String status) {
        String bizId = execution.getProcessBusinessKey();
        //根据业务id自行处理业务表
        System.out.println("业务表["+bizId+"]状态更改成功，状态更改为："+status);
    }


    //流程节点权限用户列表${ActivityDemoServiceImpl.findUsers(execution,sign)}
    @Override
    public List<String> findUsersForSL(DelegateExecution execution){
        return Arrays.asList("sly1","sly2");
    }

    //流程节点权限用户列表${ActivityDemoServiceImpl.findUsers(execution,sign)}
    @Override
    public List<String> findUsersForSP(DelegateExecution execution){
        return Arrays.asList("spy1","uspy2");
    }

    /**
     *
     * <p>描述:  生成流程图
     * 首先启动流程，获取processInstanceId，替换即可生成</p>
     * @author 范相如
     * @date 2018年2月25日
     * @param processInstanceId
     * @throws Exception
     */
    @Override
    public void queryProImg(String processInstanceId) throws Exception {
        //获取历史流程实例
        HistoricProcessInstance processInstance =  historyService.createHistoricProcessInstanceQuery().processInstanceId(processInstanceId).singleResult();

        //根据流程定义获取输入流
        InputStream is = repositoryService.getProcessDiagram(processInstance.getProcessDefinitionId());
        BufferedImage bi = ImageIO.read(is);
        File file = new File("demo2.png");
        if(!file.exists()) file.createNewFile();
        FileOutputStream fos = new FileOutputStream(file);
        ImageIO.write(bi, "png", fos);
        fos.close();
        is.close();
        System.out.println("图片生成成功");

        List<Task> tasks = taskService.createTaskQuery().taskCandidateUser("userId").list();
        for(Task t : tasks) {
            System.out.println(t.getName());
        }
    }


    /**
     * 流程图高亮显示
     * 首先启动流程，获取processInstanceId，替换即可生成
     * @throws Exception
     */
    @Override
    public String queryProHighLighted(String processInstanceId) throws Exception {
        //获取历史流程实例
        HistoricProcessInstance processInstance =  historyService.createHistoricProcessInstanceQuery().processInstanceId(processInstanceId).singleResult();
        //获取流程图
        BpmnModel bpmnModel = repositoryService.getBpmnModel(processInstance.getProcessDefinitionId());

        ProcessDiagramGenerator diagramGenerator = processEngineConfiguration.getProcessDiagramGenerator();
        ProcessDefinitionEntity definitionEntity = (ProcessDefinitionEntity)repositoryService.getProcessDefinition(processInstance.getProcessDefinitionId());

        List<HistoricActivityInstance> highLightedActivitList =  historyService.createHistoricActivityInstanceQuery().processInstanceId(processInstanceId).list();
        //高亮环节id集合
        List<String> highLightedActivitis = new ArrayList<String>();

        //高亮线路id集合
        List<String> highLightedFlows = getHighLightedFlows(definitionEntity,highLightedActivitList);

        for(HistoricActivityInstance tempActivity : highLightedActivitList){
            String activityId = tempActivity.getActivityId();
            highLightedActivitis.add(activityId);
        }
        //配置字体
        InputStream imageStream = diagramGenerator.generateDiagram(bpmnModel, "png", highLightedActivitis, highLightedFlows,"宋体","微软雅黑","黑体",null,2.0);
        BufferedImage bi = ImageIO.read(imageStream);
//        File file = new File("demo2.png");
//        if(!file.exists()) file.createNewFile();
//        FileOutputStream fos = new FileOutputStream(file);
        ByteArrayOutputStream bos= new ByteArrayOutputStream();
        ImageIO.write(bi, "png", bos);
        byte[] bytes = bos.toByteArray();//转换成字节
        BASE64Encoder encoder = new BASE64Encoder();
        String png_base64 =  encoder.encodeBuffer(bytes);//转换成base64串
        png_base64 = png_base64.replaceAll("\n", "").replaceAll("\r", "");//删除 \r\n
        bos.close();
        imageStream.close();
        return png_base64;
    }
    /**
     * 获取需要高亮的线
     * @param processDefinitionEntity
     * @param historicActivityInstances
     * @return
     */
    private List<String> getHighLightedFlows(
            ProcessDefinitionEntity processDefinitionEntity,
            List<HistoricActivityInstance> historicActivityInstances) {

        List<String> highFlows = new ArrayList<String>();// 用以保存高亮的线flowId
        for (int i = 0; i < historicActivityInstances.size() - 1; i++) {// 对历史流程节点进行遍历
            ActivityImpl activityImpl = processDefinitionEntity
                    .findActivity(historicActivityInstances.get(i)
                            .getActivityId());// 得到节点定义的详细信息
            List<ActivityImpl> sameStartTimeNodes = new ArrayList<ActivityImpl>();// 用以保存后需开始时间相同的节点
            ActivityImpl sameActivityImpl1 = processDefinitionEntity
                    .findActivity(historicActivityInstances.get(i + 1)
                            .getActivityId());
            // 将后面第一个节点放在时间相同节点的集合里
            sameStartTimeNodes.add(sameActivityImpl1);
            for (int j = i + 1; j < historicActivityInstances.size() - 1; j++) {
                HistoricActivityInstance activityImpl1 = historicActivityInstances
                        .get(j);// 后续第一个节点
                HistoricActivityInstance activityImpl2 = historicActivityInstances
                        .get(j + 1);// 后续第二个节点
                if (activityImpl1.getStartTime().equals(
                        activityImpl2.getStartTime())) {
                    // 如果第一个节点和第二个节点开始时间相同保存
                    ActivityImpl sameActivityImpl2 = processDefinitionEntity
                            .findActivity(activityImpl2.getActivityId());
                    sameStartTimeNodes.add(sameActivityImpl2);
                } else {
                    // 有不相同跳出循环
                    break;
                }
            }
            List<PvmTransition> pvmTransitions = activityImpl
                    .getOutgoingTransitions();// 取出节点的所有出去的线
            for (PvmTransition pvmTransition : pvmTransitions) {
                // 对所有的线进行遍历
                ActivityImpl pvmActivityImpl = (ActivityImpl) pvmTransition
                        .getDestination();
                // 如果取出的线的目标节点存在时间相同的节点里，保存该线的id，进行高亮显示
                if (sameStartTimeNodes.contains(pvmActivityImpl)) {
                    highFlows.add(pvmTransition.getId());
                }
            }
        }
        return highFlows;
    }
}

View Code

　 controller实现，我写了两个controller，主要当时写的时候没有写在一起，你们可以把这两部分的内容合并在一起

package com.djkj.activiti.controller;

import com.fasterxml.jackson.databind.JsonNode;
import com.fasterxml.jackson.databind.ObjectMapper;
import com.fasterxml.jackson.databind.node.ObjectNode;
import org.activiti.bpmn.converter.BpmnXMLConverter;
import org.activiti.bpmn.model.BpmnModel;
import org.activiti.editor.constants.ModelDataJsonConstants;
import org.activiti.editor.language.json.converter.BpmnJsonConverter;
import org.activiti.engine.ProcessEngine;
import org.activiti.engine.RepositoryService;
import org.activiti.engine.repository.Deployment;
import org.activiti.engine.repository.Model;
import org.apache.commons.lang3.StringUtils;
import org.apache.log4j.Logger;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;
import org.springframework.ui.ModelMap;
import org.springframework.web.bind.annotation.PathVariable;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.ResponseBody;
import org.springframework.web.bind.annotation.RestController;

import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import java.io.IOException;
import java.io.UnsupportedEncodingException;
import java.util.List;

@Controller
@RequestMapping("/models")
public class MyActivitiController {

    private static final Logger LOGGER = Logger.getLogger(MyActivitiController.class);

    @Autowired
    private RepositoryService repositoryService;
    @Autowired
    private ObjectMapper objectMapper;

    @RequestMapping("/modelList")
    public String modelList(org.springframework.ui.Model model,HttpServletRequest request){
        LOGGER.info("-------------列表页-------------");
        List<Model> models = repositoryService.createModelQuery().orderByCreateTime().desc().list();
        model.addAttribute("models",models);
        String info = request.getParameter("info");
        if(StringUtils.isNotEmpty(info)){
            model.addAttribute("info",info);
        }
        return "model/list";
    }

    @RequestMapping("/create")
    public void newModel(HttpServletRequest request, HttpServletResponse response) throws UnsupportedEncodingException {
       try {
           //初始化一个空模型
           Model model = repositoryService.newModel();

           //设置一些默认信息
           String name = "new-process";
           String description = "";
           int revision = 1;
           String key = "process";

           ObjectNode modelNode = objectMapper.createObjectNode();
           modelNode.put(ModelDataJsonConstants.MODEL_NAME, name);
           modelNode.put(ModelDataJsonConstants.MODEL_DESCRIPTION, description);
           modelNode.put(ModelDataJsonConstants.MODEL_REVISION, revision);

           model.setName(name);
           model.setKey(key);
           model.setMetaInfo(modelNode.toString());

           repositoryService.saveModel(model);
           String id = model.getId();

           //完善ModelEditorSource
           ObjectNode editorNode = objectMapper.createObjectNode();
           editorNode.put("id", "canvas");
           editorNode.put("resourceId", "canvas");
           ObjectNode stencilSetNode = objectMapper.createObjectNode();
           stencilSetNode.put("namespace",
                   "http://b3mn.org/stencilset/bpmn2.0#");
           editorNode.put("stencilset", stencilSetNode);
           repositoryService.addModelEditorSource(id, editorNode.toString().getBytes("utf-8"));

           response.sendRedirect(request.getContextPath() + "/static/modeler.html?modelId=" + id);
       }catch (IOException e){
           e.printStackTrace();
           LOGGER.info("模型创建失败！");
       }

    }

    @RequestMapping("/delete/{id}")
    public @ResponseBody String deleteModel(@PathVariable("id")String id){
        repositoryService.deleteModel(id);
        return "删除成功！";
    }


    @RequestMapping("/deployment/{id}")
    public @ResponseBody String deploy(@PathVariable("id")String id) throws Exception {

        //获取模型
        Model modelData = repositoryService.getModel(id);
        byte[] bytes = repositoryService.getModelEditorSource(modelData.getId());

        if (bytes == null) {
            return "模型数据为空，请先设计流程并成功保存，再进行发布。";
        }

        JsonNode modelNode = new ObjectMapper().readTree(bytes);

        BpmnModel model = new BpmnJsonConverter().convertToBpmnModel(modelNode);
        if(model.getProcesses().size()==0){
            return "数据模型不符要求，请至少设计一条主线流程。";
        }
        byte[] bpmnBytes = new BpmnXMLConverter().convertToXML(model);

        //发布流程
        String processName = modelData.getName() + ".bpmn20.xml";
        Deployment deployment = repositoryService.createDeployment()
                .name(modelData.getName())
                .addString(processName, new String(bpmnBytes, "UTF-8"))
                .deploy();
        modelData.setDeploymentId(deployment.getId());
        repositoryService.saveModel(modelData);
        return "流程发布成功";
    }

    @RequestMapping("/start/{id}")
    public @ResponseBody String startProcess(@PathVariable("id") String id){
        try {


        }catch (Exception e){
            e.printStackTrace();
            return "流程启动失败！";
        }
        return "流程启动成功";
    }


}

View Code

显示所有流程列表，以及流程的增删改

package com.djkj.activiti.controller;


import com.djkj.activiti.bean.ActivitiVariable;
import com.djkj.activiti.bean.FormData;
import com.djkj.activiti.service.ActivitiService;
import com.djkj.activiti.service.ActivitiVariableService;
import org.activiti.engine.HistoryService;
import org.activiti.engine.TaskService;
import org.activiti.engine.task.Task;
import org.apache.commons.lang3.StringUtils;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;
import org.springframework.ui.ModelMap;
import org.springframework.web.bind.annotation.PathVariable;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.ResponseBody;
import org.springframework.web.servlet.mvc.support.RedirectAttributesModelMap;

import javax.annotation.Resource;
import java.util.Date;
import java.util.HashMap;
import java.util.List;
import java.util.Map;

@Controller
@RequestMapping("/activiti")
public class ActivitiProcessController {
    @Resource
    private ActivitiService activitiServiceImpl;
    @Autowired
    private TaskService taskService;
    @Autowired
    private HistoryService historyService;
    @Autowired
    private ActivitiVariableService activitiVariableService;

//    private static final String business = "testtask";

    //启动流程---215001
    @RequestMapping("/start/{key}")
    public String startProcess(@PathVariable("key") String key, RedirectAttributesModelMap modelMap) {
//        Map<String,Object> map = new HashMap<String,Object>();
//        map.put("userId",userIdSl);
//        map.put("businessKey",business_key);
//        String business_key = key + ":" + key;
        ActivitiVariable activitiVariable = new ActivitiVariable();
        int resul=activitiVariableService.insert(activitiVariable);
        if(resul==1){
            modelMap.addFlashAttribute("info","流程启动成功！");
            String business_key = key+":"+activitiVariable.getId();
            activitiServiceImpl.startProcesses(key,business_key);
        }else{
            modelMap.addFlashAttribute("info","流程启动失败！");
        }
        return "redirect:/models/modelList";
    }

    //获取受理员任务列表
    @RequestMapping("/queryTaskSl")
    public String findTasksForSL(ModelMap modelMap,FormData formData) {
        List<Task> lists = activitiServiceImpl.findTasksByUserId(formData.getUserId());
        modelMap.addAttribute("tasks",lists);
        modelMap.addAttribute("userId",formData.getUserId());
        return "model/taskList";
    }


    @RequestMapping("/form")
    public String form(FormData formData,ModelMap modelMap){
        Task task=activitiServiceImpl.findTaskById(formData.getId());
        modelMap.addAttribute("data",formData);
        modelMap.addAttribute("task",task);
        if(StringUtils.isNotEmpty(task.getFormKey())){
            return "activitiForm/"+task.getFormKey();
        }
        return "model/form";
    }


    //受理员受理数据
    @RequestMapping("/completeTaskSl")
    public String completeTasksForSL(ModelMap modelMap,FormData formData) {
        activitiServiceImpl.completeTask(formData.getId(), formData.getUserId(), formData.getAttr1());//受理后，任务列表数据减少
        return findTasksForSL(modelMap,formData);
    }

//    //获取审批员任务列表
//    @RequestMapping("/queryTaskSp")
//    public void findTasksForSP() {
//        List<Task> lists = activitiServiceImpl.findTasksByUserId(userIdSp);
//        System.out.println("任务列表："+lists);//任务列表：[Task[id=220004, name=审批]]
//    }
//
//    //审批员通过审核
//    @RequestMapping("/completeTaskSp/{id}")
//    public void completeTasksForSP(@PathVariable("id")String id) {
//        activitiServiceImpl.completeTask(id, userIdSp, "true");//审批后，任务列表数据减少
//    }


    //设置流程变量
    //设置流程变量【基本类型】
    public void setTasksVar() {
        List<Task> lists = activitiServiceImpl.findTasksByUserId("sly1");
        for(Task task : lists) {//不知为何，变量保存成功，但数据表只有请假天数含有任务id，单获取流程变量时，根据任务id均可获取到（如下一测试）
            taskService.setVariable(task.getId(), "请假人", "sly1");
            taskService.setVariableLocal(task.getId(), "请假天数",3);
            taskService.setVariable(task.getId(), "请假日期", new Date());
        }
    }

//    //获取流程变量
//    @Test
//    public void getTasksVar() {
//        List<Task> lists = activitiServiceImpl.findTasksByUserId("sly1");
//        for(Task task : lists) {
//            //获取流程变量【基本类型】
//            String person = (String) taskService.getVariable(task.getId(), "请假人");
//            Integer day = (Integer) taskService.getVariableLocal(task.getId(), "请假天数");
//            Date date = (Date) taskService.getVariable(task.getId(), "请假日期");
//
//            System.out.println("流程变量："+person+"||"+day+"||"+date+"||");
//        }
//    }
//
//    //设置流程变量【实体】
//    @Test
//    public void setTasksVarEntity() {
//        List<Task> lists = activitiServiceImpl.findTasksByUserId("sly1");
//        for(Task task : lists) {
//            Person p = new Person();
//            p.setName("翠花");
//            p.setId(20);
//            p.setDate();;
//            p.setNote("回去探亲，一起吃个饭123");
//            taskService.setVariable(task.getId(), "人员信息(添加固定版本)", p);
//
//            System.out.println("设置流程变量成功！");
//        }
//    }
//
//    //获取流程变量【实体】  实体必须序列化
//    @Test
//    public void getTasksVarEntity() {
//        List<Task> lists = activitiServiceImpl.findTasksByUserId("sly1");
//        for(Task task : lists) {
//            // 2.获取流程变量，使用javaBean类型
//            Person p = (Person)taskService.getVariable(task.getId(), "人员信息(添加固定版本)");
//            System.out.println(" 请假人：  "+p.getName()+"  请假天数：  "+p.getId()+"   请假时间："+ p.getDate()+ "   请假原因： "+p.getNote());
//        }
//    }
//
//
//    //生成流程图---232501
//    @RequestMapping("/queryProImg")
//    public void queryProImg() throws Exception {
//        activitiServiceImpl.queryProImg("232501");
//    }

    //生成流程图（高亮）---232501
    @RequestMapping("/queryProHighLighted")
    public @ResponseBody String queryProHighLighted(String proInsId) throws Exception {
        String imageByteArray = activitiServiceImpl.queryProHighLighted(proInsId);
        return imageByteArray;
    }
//
//    /**
//     * 查询流程变量的历史表,可以根据变量名称查询该变量的所有历史信息
//     */
//    @Test
//    public void findHistoryProcessVariables(){
//        List<HistoricVariableInstance> list = historyService.createHistoricVariableInstanceQuery()//创建一个历史的流程变量查询对象
//                .variableName("请假天数")
//                .list();
//        if (list!=null &&list.size()>0) {
//            for (HistoricVariableInstance hvi : list) {
//                System.out.println(hvi.getId()+"     "+hvi.getProcessInstanceId()+"   "+hvi.getVariableName()
//                        +"   "+hvi.getVariableTypeName()+"    "+hvi.getValue());
//                System.out.println("########################################");
//            }
//        }
//
//    }
//
//
//    /**
//     *  历史流程实例查询
//     *  http://blog.csdn.net/luckyzhoustar/article/details/48652783
//     */
//    @Test
//    public void findHistoricProcessInstance() {
//        // 查询已完成的流程
//        List<HistoricProcessInstance> datas = historyService
//                .createHistoricProcessInstanceQuery().finished().list();
//        System.out.println("使用finished方法：" + datas.size());
//        // 根据流程定义ID查询
//        datas = historyService.createHistoricProcessInstanceQuery()
//                .processDefinitionId("processDefinitionId").list();
//        System.out.println("使用processDefinitionId方法： " + datas.size());
//        // 根据流程定义key（流程描述文件的process节点id属性）查询
//        datas = historyService.createHistoricProcessInstanceQuery()
//                .processDefinitionKey("processDefinitionKey").list();
//        System.out.println("使用processDefinitionKey方法： " + datas.size());
//        // 根据业务主键查询
//        datas = historyService.createHistoricProcessInstanceQuery()
//                .processInstanceBusinessKey("processInstanceBusinessKey").list();
//        System.out.println("使用processInstanceBusinessKey方法： " + datas.size());
//        // 根据流程实例ID查询
//        datas = historyService.createHistoricProcessInstanceQuery()
//                .processInstanceId("processInstanceId").list();
//        System.out.println("使用processInstanceId方法： " + datas.size());
//        // 查询没有完成的流程实例
//        historyService.createHistoricProcessInstanceQuery().unfinished().list();
//        System.out.println("使用unfinished方法： " + datas.size());
//    }
//
//    /**
//     *  历史任务查询
//     * @throws ParseException
//     */
//    @Test
//    public void findHistoricTasks() throws ParseException {
//        SimpleDateFormat sdf = new SimpleDateFormat("yyyy-MM-dd HH:mm:ss");
//
//        //历史数据查询
//        List<HistoricTaskInstance> datas = historyService.createHistoricTaskInstanceQuery()
//                .finished().list();
//        System.out.println("使用finished方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .processDefinitionId("processDefinitionId").list();
//        System.out.println("使用processDefinitionId方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .processDefinitionKey("testProcess").list();
//        System.out.println("使用processDefinitionKey方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .processDefinitionName("testProcess2").list();
//        System.out.println("使用processDefinitionName方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .processFinished().list();
//        System.out.println("使用processFinished方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .processInstanceId("processInstanceId").list();
//        System.out.println("使用processInstanceId方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .processUnfinished().list();
//        System.out.println("使用processUnfinished方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .taskAssignee("crazyit").list();
//        System.out.println("使用taskAssignee方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .taskAssigneeLike("%zy%").list();
//        System.out.println("使用taskAssigneeLike方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .taskDefinitionKey("usertask1").list();
//        System.out.println("使用taskDefinitionKey方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .taskDueAfter(sdf.parse("2020-10-11 06:00:00")).list();
//        System.out.println("使用taskDueAfter方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .taskDueBefore(sdf.parse("2022-10-11 06:00:00")).list();
//        System.out.println("使用taskDueBefore方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .taskDueDate(sdf.parse("2020-10-11 06:00:00")).list();
//        System.out.println("使用taskDueDate方法查询：" + datas.size());
//        datas = historyService.createHistoricTaskInstanceQuery()
//                .unfinished().list();
//        System.out.println("使用unfinished方法查询：" + datas.size());
//    }
//    /**
//     *  历史行为查询
//     *  流程在进行过程中，每每走一个节点，都会记录流程节点的信息，包括节点的id，名称、类型、时间等，保存到ACT_HI_ACTINST表中。
//     * @throws ParseException
//     */
//    @Test
//    public void findHistoricActivityInstance() {
//        SimpleDateFormat sdf = new SimpleDateFormat("yyyy-MM-dd HH:mm:ss");
//
//        //查询数据
//        List<HistoricActivityInstance> datas = historyService.createHistoricActivityInstanceQuery()
//                .activityId("endevent1").list();
//        System.out.println("使用activityId查询：" + datas.size());
//        datas = historyService.createHistoricActivityInstanceQuery()
//                .activityInstanceId(datas.get(0).getId()).list();
//        System.out.println("使用activityInstanceId查询：" + datas.size());
//        datas = historyService.createHistoricActivityInstanceQuery()
//                .activityType("intermediateSignalCatch").list();
//        System.out.println("使用activityType查询：" + datas.size());
//        datas = historyService.createHistoricActivityInstanceQuery()
//                .executionId("executionId").list();
//        System.out.println("使用executionId查询：" + datas.size());
//        datas = historyService.createHistoricActivityInstanceQuery().finished().list();
//        System.out.println("使用finished查询：" + datas.size());
//        datas = historyService.createHistoricActivityInstanceQuery()
//                .processInstanceId("processInstanceId").list();
//        System.out.println("使用processInstanceId查询：" + datas.size());
//        datas = historyService.createHistoricActivityInstanceQuery()
//                .taskAssignee("crazyit").list();
//        System.out.println("使用taskAssignee查询：" + datas.size());
//        datas = historyService.createHistoricActivityInstanceQuery().unfinished().list();
//        System.out.println("使用unfinished查询：" + datas.size());
//    }
//
//    /**
//     *  历史流程明细查询
//     *  在流程进行的过程中，会产生许多明细数据，只有将History设置为最高级别的时候，才会被记录到ACT_HI_DETAIL表中。
//     * @throws ParseException
//     */
//    @Test
//    public void findHistoricDetail() {
//        // 查询历史行为
//        HistoricActivityInstance act = historyService.createHistoricActivityInstanceQuery()
//                .activityName("First Task").finished().singleResult();
//        List<HistoricDetail> datas = historyService.createHistoricDetailQuery()
//                .activityInstanceId(act.getId()).list();
//        System.out.println("使用activityInstanceId方法查询：" + datas.size());
//        datas = historyService.createHistoricDetailQuery().excludeTaskDetails().list();
//        System.out.println("使用excludeTaskDetails方法查询：" + datas.size());
//        datas = historyService.createHistoricDetailQuery().formProperties().list();
//        System.out.println("使用formProperties方法查询：" + datas.size());
//        datas = historyService.createHistoricDetailQuery().processInstanceId("processInstanceId").list();
//        System.out.println("使用processInstanceId方法查询：" + datas.size());
//        datas = historyService.createHistoricDetailQuery().taskId("taskId").list();
//        System.out.println("使用taskId方法查询：" + datas.size());
//        datas = historyService.createHistoricDetailQuery().variableUpdates().list();
//        System.out.println("使用variableUpdates方法查询：" + datas.size());
//    }

}

View Code

启动流程、用户任务task查询、业务处理、流程进度查看等等，历史流程查看功能没有验证过，这部分代码是注释掉的

5、页面实现
　　在templates放置显示页面，可自己根据喜好放置，我这里主要是跟controller里返回的路径对应
技术分享图片

　　model文件夹下放的是模型列表页和用户任务列表页，form.html已经废弃，改为上面的activitiForm里面的form页面，不同的页面对应不同流程节点

　　
list.html模型列表页

<!DOCTYPE html>
<html lang="zh" xmlns:th="http://www.thymeleaf.org">
<head>
    <meta charset="UTF-8">
    <title>Title</title>
    <script src="/static/js/jquery.min.js"></script>
    <script th:inline="javascript">
        function deployment(obj){
            var id=obj.attributes[‘objectid‘].nodeValue;
            $.ajax({
                url:"/models/deployment/"+id,
                type:"GET",
                success:function(res){
                    alert(res);
                }
            });

        }

        function deleteProcess(obj){
            var id=obj.attributes[‘objectid‘].nodeValue;
            $.ajax({
                url:"/models/delete/"+id,
                type:"GET",
                success:function(res){
                    alert(res);
                }

            });

        }

        function start(obj){
            var id=obj.attributes[‘objectid‘].nodeValue;
            $.ajax({
                url:‘/models/start/‘+id,
                type:‘GET‘,
                success:function(res){
                    alert(res);
                }
            });


        }

        function taskList(){
            $("#taskList").submit();
        }
    </script>
</head>
<body>
<div class="info"><span th:text="${info}"></span></div>
<a href="/models/create">新建</a>
<form id="taskList" action="/activiti/queryTaskSl">
<div>
    <div style="float:left;width:50%;">
        <select id="userId" name="userId">
            <option value="userzhou">userzhou</option>
            <option value="usertest">usertest</option>
        </select>
    </div>
    <div style="width:50%;">
        <button onclick="taskList();">任务列表</button>
    </div>
</div>
</form>

<table class="table">
    <thead>
    <tr>
        <th>ID</th>
        <th>模型名称</th>
        <th>key</th>
        <th>版本</th>
        <th>部署ID</th>
        <th>创建时间</th>
        <th>最后更新时间</th>
        <th>操作</th>
    </tr>
    </thead>
    <tbody>
    <tr th:each="data : ${models}">
        <td th:text="${data.id}"></td>
        <td><a th:href="@{/static/modeler.html(modelId=${data.id})}" class="font-blue" th:text="${data.name}"></a>
        </td>
        <td th:text="${data.key}"></td>
        <td th:text="${data.version}"></td>
        <td th:text="${data.deploymentId}"></td>
        <td th:text="${data.createTime}"> 2018-02-25 17:28:35</td>
        <td th:text="${data.lastUpdateTime}"> 2018-02-25 17:28:35</td>
        <td><a href="javascript:void(0);" onclick="deployment(this);" th:attrappend="objectId=${data.id}" lass="font-blue deployBtn">发布</a>
            <a th:href="${‘/activiti/start/‘+data.key}" th:attrappend="objectId=${data.id}" lass="font-blue deployBtn">发起流程</a>
            <a th:href="@{/crm/model/export/{modelId}(modelId=${data.id})}" class="font-blue">导出</a>
            <a href="javascript:void(0);" onclick="deleteProcess(this);" th:attrappend="objectId=${data.id}" class="font-blue delBtn">删除</a></td>
    </tr>
    </tbody>
</table>
</body>
</html>

View Code

taskList.html任务列表页

<!DOCTYPE html>
<html lang="zh" xmlns:th="http://www.thymeleaf.org">
<head>
    <meta charset="UTF-8">
    <title>Title</title>
    <script src="/static/js/jquery.min.js"></script>
</head>
<body>
<a href="/models/modelList"><button>返回模型列表页</button></a>
<div>
    <span th:text="‘用户：‘+${userId}"></span>
    <table>
        <thead>
        <tr>
            <th>ID</th>
            <th>任务名称</th>
            <th>受理人</th>
            <th>任务ID</th>
            <th>流程ID</th>
            <th>创建时间</th>
            <th>操作</th>
        </tr>
        </thead>
        <tbody>
        <tr th:each="data : ${tasks}">
            <td th:text="${data.id}">LeaveBill:1:4</td>
            <td th:text="${data.name}"></td>
            <td th:text="${data.assignee}">1</td>
            <td th:text="${data.taskDefinitionKey}"></td>
            <td th:text="${data.processDefinitionId}"></td>
            <td th:text="${data.createTime}"> 2018-02-25 17:28:35</td>
            <td>
                <a th:href="${‘/activiti/form?id=‘+data.id+‘&userId=‘+data.assignee}" th:attrappend="objectId=${data.id}" lass="font-blue deployBtn">处理</a>
            </td>
        </tr>
        </tbody>
    </table>
</div>
</body>
</html>

View Code

applyForm.html任务列表页

<!DOCTYPE html>
<html lang="zh" xmlns:th="http://www.thymeleaf.org">
<head>
    <meta charset="UTF-8">
    <title>申请页面</title>
    <script src="/static/js/jquery.min.js"></script>
    <style>
        .title{
            text-align: center;
        }
    </style>
    <script>
        function showProcessImg(processInstanceId) {
            $.ajax({
                url:‘/activiti/queryProHighLighted‘,
                type:‘POST‘,
                data:{
                    proInsId:processInstanceId
                },
                success:function(res){
                }
            })
        }
        function returnBack(userId){
            var form = $("<form></form>");
            form.attr("action","/activiti/queryTaskSl");
            form.attr("method","post");

            var input = $("<input type=‘text‘ name=‘userId‘/>")
            input.attr("value",userId);
            form.append(input);

            form.appendTo("body");

            form.css("display","none");

            form.submit();

        }
    </script>
</head>
<body>
<div class="title">申请表单</div>
<a th:onclick="‘javascript:returnBack(\‘‘+${data.userId}+‘\‘);‘"><button>返回用户任务列表</button></a>
<a href="javascript:void(0);" th:onclick="‘javascript:showProcessImg(\‘‘+${task.processInstanceId}+‘\‘)‘"><button>查看流程图</button></a>
<form action="/activiti/completeTaskSl">
    <input type="hidden" id="id" name="id" th:value="${data.id}"/>
    <input type="hidden" id="userId" name="userId" th:value="${data.userId}"/>
    <input type="text" id="attr1" name="attr1"/>
    <button type="submit">提交</button>
    <button>取消</button>
</form>
<img src="" id="processImg"/>
</body>
</html>

View Code

　

approveForm.html任务列表页

<!DOCTYPE html>
<html lang="zh" xmlns:th="http://www.thymeleaf.org">
<head>
    <meta charset="UTF-8">
    <title>审批页面</title>
    <script src="/static/js/jquery.min.js"></script>
    <style>
        .title{
            text-align: center;
        }
    </style>
    <script>
        function showProcessImg(processInstanceId) {
            $.ajax({
                url:‘/activiti/queryProHighLighted‘,
                type:‘POST‘,
                data:{
                    proInsId:processInstanceId
                },
                success:function(res){
                }
            })
        }

        function returnBack(userId){
            var form = $("<form></form>");
            form.attr("action","/activiti/queryTaskSl");
            form.attr("method","post");

            var input = $("<input type=‘text‘ name=‘userId‘/>")
            input.attr("value",userId);
            form.append(input);

            form.appendTo("body");

            form.css("display","none");

            form.submit();

        }
    </script>
</head>
<body>
<div class="title">审批表单</div>
<a th:onclick="‘javascript:returnBack(\‘‘+${data.userId}+‘\‘);‘"><button>返回任务列表</button></a>
<a href="javascript:void(0);" th:onclick="‘javascript:showProcessImg(\‘‘+${task.processInstanceId}+‘\‘)‘"><button>查看流程图</button></a>
<form action="/activiti/completeTaskSl">
    <input type="hidden" id="id" name="id" th:value="${data.id}"/>
    <input type="hidden" id="userId" name="userId" th:value="${data.userId}"/>
    <input type="text" id="attr1" name="attr1"/>
    <button type="submit">提交</button>
    <button>取消</button>
</form>
<img src="" id="processImg"/>
</body>
</html>

View Code

运行界面如下
list.html列表页

新建页面

这里主要注意连个地方，assignments表示当前节点的处理人的id，我自己定义了两个用户userzhou和usertest，form key填写处理当前节点所用的form表单，也就是之前的applyForm和approveForm

需要注意的地方

1、去除activiti的security校验，修改application启动类
@SpringBootApplication(scanBasePackages = {"com.djkj","org.activiti"} , exclude = { org.springframework.boot.autoconfigure.security.servlet.SecurityAutoConfiguration.class, org.activiti.spring.boot.SecurityAutoConfiguration.class,})
这是按照网上的写的，但还是存在校验，最后没办法在act_id_user里面加了一条数据

2、访问静态资源的时候，可能会被dispatcherservlet 给拦截掉，我是添加了个资源处理器，拦截static静态资源

package com.djkj.activiti.common;

import groovy.util.logging.Slf4j;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.servlet.config.annotation.EnableWebMvc;
import org.springframework.web.servlet.config.annotation.ResourceHandlerRegistry;
import org.springframework.web.servlet.config.annotation.WebMvcConfigurer;

@Configuration
@Slf4j
@EnableWebMvc
public class StaticResourceConfig implements WebMvcConfigurer {

    @Override
    public void addResourceHandlers(ResourceHandlerRegistry registry) {
        registry.addResourceHandler("/static/**").addResourceLocations("classpath:/static/");
    }

}

View Code

3、关闭编辑器的时候可以自定义返回的页面
　　修改editor-app\configuration下的toolbar-default-actions.js，有俩个地方closeEditor方法和$scope.saveAndClose方法，一个是关闭一个是保存并关闭，可以修改放回路径，对应的是controller里的路径

  closeEditor: function(services) {
            window.location.href = "/models/modelList";
        },

$scope.saveAndClose = function () {
        $scope.save(function() {
            window.location.href = "/models/modelList";
        });
    };

原文：https://www.cnblogs.com/zhouyun-yx/p/10410274.html

springBoot2集成activiti，集成activiti在线设计器

摘要

所需软件版本springBoot 2.0.1.RELEASEactiviti 5.22.0 官网下载地址activiti-webapp-explorer2 我的github上的explorer项目

集成方法activiti支持多种数据库，本身还有个h2的内存数据库，我这里用的是Mysql1、pom.xml引入依赖，这里主要是activiti的依赖包，${activiti.version}为5.22.0

运行界面如下list.html列表页新建页面这里主要注意连个地方，assignments表示当前节点的处理人的id，我自己定义了两个用户userzhou和usertest，form key填写处理当前节点所用的form表单，也就是之前的applyForm和approveForm

3、关闭编辑器的时候可以自定义返回的页面 修改editor-app\configuration下的toolbar-default-actions.js，有俩个地方closeEditor方法和$scope.saveAndClose方法，一个是关闭一个是保存并关闭，可以修改放回路径，对应的是controller里的路径

所需软件版本
springBoot 2.0.1.RELEASE
activiti 5.22.0 官网下载地址
activiti-webapp-explorer2 我的github上的explorer项目

集成方法
activiti支持多种数据库，本身还有个h2的内存数据库，我这里用的是Mysql
1、pom.xml引入依赖，这里主要是activiti的依赖包，${activiti.version}为5.22.0

运行界面如下
list.html列表页

新建页面

这里主要注意连个地方，assignments表示当前节点的处理人的id，我自己定义了两个用户userzhou和usertest，form key填写处理当前节点所用的form表单，也就是之前的applyForm和approveForm

3、关闭编辑器的时候可以自定义返回的页面
　　修改editor-app\configuration下的toolbar-default-actions.js，有俩个地方closeEditor方法和$scope.saveAndClose方法，一个是关闭一个是保存并关闭，可以修改放回路径，对应的是controller里的路径
